EMBLA SBC

EMBLA SBC

Embla SBC is a self adjusting stripping and cutting tool, 0.02-10 mm²/AWG 34-8, Straight blade.

  • Tool-less interchangeable stripping cassettes allow a wide and diverse stripping capacity
  • Widest stripping capacity of any tool of its type
  • Durable, integrated wire cutting capability
  • Cutting capacity: Flexible wires, 10 mm²/8 AWG. Rigid wires, 1.5 mm² /16 AWG
  • Fine adjustability for thin or thick insulation, without damage to wire conductors
  • At the end of the stripping function, the stripping blades open and remain open to facilitate easy and snag free wire removal from the tool
  • Ergonomic: strong, durable, and comfortable ergonomic design
  • Replacement stripping cassettes and cutting blades available
  • Reliable: Frame and mechanism life span exceeds 150,000 cycles (tested with 1.5 mm²/AWG 16 PVC cable).

All three cassettes (grey, red and blue) are available as separate items.Kasetter-Embla_600x200

TECHNICAL DATA

191 mm/7.52"
20 mm/0.79"
90 mm/3.54"
136 gr/0.3 lb
0.02-10 mm2 / AWG 34-8

3-18 mm/adjustable

0.12-0.71''/adjustable
PVC
Self-adjusting cutting and stripping tool for electrical installation and equipment wires in PVC insulation.
150,000 (tested with 1.5 mm²/AWG 16 PVC cable)
